| Fourth axis | |
|---|---|
| Fourth axis three-jaw lathe chuck | 200 mm |
| Table diameter | 120 mm |
| Fourth axis Center height table vertical | 115 mm |
| Total vertical height without motor cover | 193 mm |
| Horizontal table height | 170 mm |
| Workpiece weight horizontal max. | 75 kg |
| Workpiece weight vertical max. | 35 kg |
Fourth axle complete set
Rotary indexing table three-jaw lathe chuck Ø 200 mm, tailstock
Price upon request
Prices are recommended retail prices. Retailer prices may vary.
Art.-No. 3511409051
Are you interested in this product?
Put a request
Find Trader
Productdetails
- Table diameter 120 mm
- Vertical table center height 115 mm
- Total vertical height without motor cover 193 mm
- Horizontal table height 170 mm
- Workpiece weight horizontal / vertical max. 75 / 35 kg
| VPE | 1 |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
If a guarantee is shown in the article description and/or in the description of the scope of delivery, your legal rights of liability for defects towards your seller remain unaffected. For the scope, duration, content and the guarantor, please refer to the guarantee conditions. We are not liable for printing errors, mistakes or incorrect presentation. Technical and optical changes are reserved. Fig. partly with optional accessories. Delivery is made exclusively according to our terms of delivery and payment. The sale is carried out via the specialized trade.
Optional parts
Optional parts can not be retrofitted and are available only when ordering new machines.
