Surface and thickness planer
ADH 41
For dressing solid wood boards, planks and strips
4.799,00
EUR excl. Tax / pc(s).
5.758,80 EUR incl. 20% Tax / pc(s).
5.758,80 EUR incl. 20% Tax / pc(s).
Promotional price *
4.399,00 EUR excl. Tax / pc(s).5.278,80 EUR incl. 20% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
* Promotional price valid until 28.02.2025 in Germany.
Art.-No. 5940041
Are you interested in this product?
Put a request
Find Trader
Productdetails
- Thickness planer for accurate, angular planing of smooth surfaces
- Thicknessing table with central column guide, additional guide and mechanical counter (accuracy 0,1mm)
- Large dimensioned planing tables made of grey cast iron with ground surface
- Folding up of the planing tables with spring support for a quick and comfortable changeover to thicknessing in seconds
- Stable professional planing fence can be swivelled from 90 to +45°
- Space-saving lateral guidance of the planing fence
- High-quality workmanship and ergonomic design
- Oblong hole drilling device available as accessory
- Thickness planer for planing smooth surfaces at an angle and with high accuracy
- Stable professional planing fence swivels from 90 to +45°.
- Simultaneous folding up of the jointer tables with spring support for fast and convenient changeover to thicknessing in seconds
- Large-dimensioned dressing table made of grey cast iron with ground surface
| Dimensions and weights | |
|---|---|
| Length approx. | 1800 mm |
| Width/depth approx. | 740 mm |
| Height approx. | 1000 mm |
| Weight approx. | 420 kg |
| Electrical Data | |
|---|---|
| Absorbed power drive motor | 5.5 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Extraction port | |
|---|---|
| Extraction port diameter thickness | 120 mm |
| Feed | |
|---|---|
| Speed | 8 m/min |
| Jointing | |
|---|---|
| Max. cutting depth | 5 mm |
| Planing stop pivoting range | 90 – 45 ° |
| Planing knife shaft | |
|---|---|
| Type | Strip planer blade shaft |
| Number of planing blades | 4 St |
| Speed | 4600 min¯¹ |
| Max. planing width | 410 mm |
| Thickness | |
|---|---|
| Working height min. | 4 mm |
| Working height max. | 225 mm |
| Working length min. | 300 mm |
| Max. cutting depth | 5 mm |
| VPE | 1 |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
- Turning planer knife mounted
- Professional side dresser stop
